Main Features
- Auto Capture Switch is integrated for scanning without pushing buttons.
- Robust system for high-end cameras.
- Assisted camera positioning.
- Uniform light distribution makes your image well, evenly lid.
- Glare-free results on glossy paper.
- All Scan Modes are available - Color(24 bit), Grayscale(8 bit) and Bitonal B&W (1 bit)
- Supports many Resolutions, Up to 600 PPI (depends on Camera, Lens and Document Size)
- Many Image formats are available: Uncompressed RAW format, lossless TIFF (CCITT Group 4), TIFF (LZW), JPEG, and PDF
- Power Supply: Standard 120-240 VAC, 50/60 Hz
Document Capturing
|
Scanning Head:
|
Twin CMOS sensors, DSLR Cameras.
|
|
Pixels:
|
Up to 21.1 megapixel (Depend on Camera), 24 bit RGB (5,616 x 3,744 pixels).
|
|
Optical Resolution:
|
Up to 600 PPI (depends on Camera Pixels, Lens Type and Document Size)
|
|
Illumination:
|
LED lighting panels. UV free, IR free.
|
|
Document Size:
|
10 x 15 inches (25.5 x 38 cm) - Up to A3 (2 x A4). No lower limit.
|
|
Scanning Speed:
|
Less than 2 second for all Documents. Color – Size – Resolution Independent.
|
|
Paper Type:
|
All Paper Type
|
|
Document Thickness:
|
More than 5 cm
|
|
Capturing Software:
|
BookDrive Capture
|
|
Editing Software:
|
BookDrive Editor Pro
|
| Dimensions (W x D x H x Wight): |
32”x 40” x 34” x 57 lbs - 82 cm x 102 cm x 86 cm x 26 kg |
|
